PRESSURE VESSEL MECHANICAL DESIGN AND DETAILING

PRESSURE VESSEL MECHANICAL DESIGN AND DETAILING

About Image
  • Mechanical design of Pressure Vessels, Columns, Reactors & Tanks as per International Standard Codes.
  • Design & Analysis of Pressure Vessel (Tall Columns, Vertical Pressure Vessels, Horizontal Pressure Vessels, Reactors etc.) as per ASME Section VIII Div 1 & 2, Section II, PD5500 etc.
  • Re-rating of existing pressure vessels for a new set of design parameters.
  • Finite Element Analysis for Pressure Vessels and Pressure Vessel components.
  • Fitness-for-service evaluations for pressure vessels to assure the structural integrity of equipment.
  • Design as per PV-Elite, ANSYS tools.
  • General arrangement drawing & detailed fabrication drawings.
  • Combined Loading Calculation for Tall Columns / Vessels
  • Doing Local Load calculations for nozzles & supports as per WRC, PD5500 etc.
  • Static Analysis of Vessels for Wind and Seismic Forces.
  • Fatigue analysis to calculate the fatigue life of pressure vessels subjected to pressure cycles, temperature cycles and start up / shutdown cycles.
  • Detailed Material Take Off
